Specifications
Typical values from the datasheet; accuracy applies under the datasheet's reference conditions. Where a value depends on the application it is specified per project and fixed in the order confirmation.
| function | multi-level gas monitoring & alarm controller |
| field devices | up to 30 analyzers per cabinet |
| architecture | 3 levels · field → GDC cabinet → SCADA |
| protocols | Modbus RTU / TCP/IP · IEC 60870-5-104 |
| I/O | up to 112 relay outputs · 4–20 mA · RS-485 |
| enclosure | 600×600×250 mm · 26 kg · IP65 · 230 V AC |
Downloads
Open links — no form.
| Document | File | Type |
|---|---|---|
| Datasheet | tremon-gdc-datasheet.pdf | PDF · 4 MB |
| Manual | tremon-gdc-manual.pdf | PDF · 6 MB |
| Calibration certificate (sample) | on request — issued per unit | |
| Modbus register map | on request |
Applications and the rule behind each
- Substation / GIS gas-detection systems with IR·SF₆ transmitters
- Plant-wide toxic & combustible gas alarm systems
- CEMS data concentration and reporting to the control room
- Ventilation and shutdown interlocks
Gases
Each gas has a reference page with limits, IR band and monitoring practice.
Certificates and compliance
Status words as on the datasheet: certified · pending · application dependent.
| CE (EMC, LVD) | certified |
| IP65 | certified |
| SIL | not claimed — alarm logic per project |
How you get it
1
number of points · protocols · alarm logic
2
system design & quote
3
FAT · delivery · commissioning
4
service contract
FAQ
How many field devices?
Up to 30 analyzers per cabinet over RS-485 Modbus RTU; several cabinets scale over Modbus TCP / IEC 60870-5-104.
Alarm logic?
Multi-level thresholds per point, relay groups for ventilation and shutdown, event log — configured at FAT.
SCADA integration?
Modbus TCP and IEC 60870-5-104; register maps delivered with the documentation pack.
Get a quote
Tell us what you measure — just tap
Three taps and an email. An engineer replies within 24 h with feasibility and a price indication.
